Lem PN16/SDR21 PVDF Plus
- Ďalšie informácie
Ďalšie informácie
| d(mm) | 20, 25, 32, 40, 50, 63, 75, 90, 110, 140, 160, 200, 225, 250, 280, 315 |
|---|---|
| DN | 100, 125, 15, 150, 20, 200, 225, 25, 250, 300, 32, 40, 50, 65, 80 |
| PN(bar) | 16 |
| Zváranie | BCF,IR, IR |
| Kat. číslo | d(mm) | DN | PN(bar) | Zváranie | Množstvo | |
|---|---|---|---|---|---|---|
| 735 798 831 | 20 | 15 | 16 | BCF,IR | ||
| 735 798 832 | 25 | 20 | 16 | BCF,IR | ||
| 735 798 833 | 32 | 25 | 16 | BCF,IR | ||
| 735 798 834 | 40 | 32 | 16 | BCF,IR | ||
| 735 798 835 | 50 | 40 | 16 | BCF,IR | ||
| 735 798 836 | 63 | 50 | 16 | BCF,IR | ||
| 735 798 837 | 75 | 65 | 16 | BCF,IR | ||
| 735 798 838 | 90 | 80 | 16 | BCF,IR | ||
| 735 798 839 | 110 | 100 | 16 | BCF,IR | ||
| 735 798 841 | 140 | 125 | 16 | IR | ||
| 735 798 842 | 160 | 150 | 16 | IR | ||
| 735 798 844 | 200 | 200 | 16 | IR | ||
| 735 798 845 | 225 | 200 | 16 | IR | ||
| 735 798 846. | 250 | 250 | 16 | IR | ||
| 735 798 847. | 280 | 250 | 16 | IR | ||
| 735 798 848. | 315 | 300 | 16 | IR |
